How to Get Square Footage from a Matterport Floor Plan

Matterport 3D tours are everywhere in real estate listings, but the floor plans they generate deliberately leave out total square footage. Here is why, and how to calculate it yourself in under two minutes.

Measure Your Floor Plan in Minutes

Upload a plan, set the scale with one known wall, and measure anything: wall lengths, room areas, and total size. Your first measurement is free, no signup required.

Upload Floor Plan

Why Matterport floor plans do not show square footage

Matterport uses LiDAR sensors and photogrammetry to produce highly accurate 3D models and 2D floor plans. Their plans are used in hundreds of thousands of listings and are generally considered among the most precise in the industry. Scans made with the Pro camera or an iPhone 12 Pro and later are typically accurate to within 1–2% of a physical measurement; non-LiDAR phone scans run closer to 2–4%.

Yet despite all that precision, Matterport floor plans do not include a total square footage figure. The reason is almost certainly liability. Square footage in real estate is a legally sensitive number. If Matterport published a GLA figure that differed from what an appraiser measured, they could find themselves in the middle of every deal dispute. By omitting the total, they stay out of it.

The same pattern holds for CubiCasa, iGUIDE, and most other floor plan services. Accurate, to-scale plans. No total.

What you get from a Matterport plan

A Matterport floor plan does give you individual room dimensions. You can see that the living room is 14 ft by 18 ft, the master bedroom is 12 ft by 15 ft, and so on. What it does not give you is a single gross living area (GLA) figure that accounts for wall thickness, irregular shapes, and how all the rooms connect.

Adding up individual room areas also produces an inaccurate result because it ignores hallways, closets, wall thickness, and any non-rectangular geometry. The only reliable method is to trace the exterior perimeter and measure from the outside.

How to calculate square footage from a Matterport floor plan

The most accurate approach is to use the 2D floor plan image from the Matterport tour and measure the exterior perimeter directly using a floor plan measurement tool. Here is how to do it with MeasureFloorPlan:

Export the schematic floor plan from Matterport. In your dashboard (my.matterport.com), open the tour settings and select Export, then Schematic Floor Plans. This downloads a ZIP with a JPG per floor plus a PDF. If you're a buyer without dashboard access, open the tour in a browser, switch to the floor plan view, and take a high-resolution screenshot at full zoom.
Upload to MeasureFloorPlan. The exported files are high resolution and trace cleanly. For multi-story homes, upload each floor separately; Matterport labels each file by level.
Set the scale. Click the two endpoints of any wall with a labeled dimension and enter the real length. Use the longest labeled dimension you can find, and every measurement you draw afterward shows its true length.
Trace the exterior perimeter of the above-grade living space, or let auto-detect do it. Matterport plans show the full footprint including the garage: exclude it from your GLA polygon, and add a separate polygon for the garage if you need it broken out. Ignore furniture drawn inside the plan.
Read the total. Each polygon shows its area once traced. For a two-story home, sum the floor totals for full GLA.

The entire process takes about two minutes per floor on a clean Matterport plan.

Matterport vs. CubiCasa floor plan accuracy

Factor	Matterport	CubiCasa
Capture method	3D LiDAR scan → 2D projection	LiDAR + photogrammetry → 2D floor plan
Plan style	More complex geometry; full 3D detail projected	Cleaner line drawings; consistent wall thickness
Square footage shown?	No, must calculate from plan	No, same; calculate using MeasureFloorPlan
Accuracy for GLA calc	High, ~1–2% with proper calibration	High, ~1% with proper calibration
Works with MeasureFloorPlan?	Yes	Yes
Typical use	High-end listings; luxury market 3D tours	Agent-ordered floor plans; Bay Area standard

Both services produce to-scale plans that work well with MeasureFloorPlan. Matterport plans tend to have slightly more complex geometry because they capture the full 3D model and then project it to 2D. CubiCasa plans are often cleaner line drawings with more consistent wall thicknesses.

In practice, both work reliably. If the auto-detection misses an irregular corner or an open doorway creates a gap in the perimeter, use the manual trace tool to click the exterior boundary yourself. It takes less than a minute.

Who needs this

Real estate appraisers frequently encounter Matterport plans when appraising listings in markets where 3D tours are standard. The plan is accurate and to-scale, which makes it a reliable data source, but without square footage, it is not immediately usable for a GLA calculation.

Buyers and agents use this to independently verify listed square footage before an offer or before a listing goes live. On a transaction over $500K, a 50 square foot discrepancy can represent tens of thousands of dollars in value.

More guides on floor plan measurement tools:

← Back to: Floor Plan Measurement Tools: The Complete Comparison Guide

Measure Your Floor Plan in Minutes

Upload a plan, set the scale with one known wall, and measure anything: wall lengths, room areas, and total size. Your first measurement is free, no signup required.

Upload Floor Plan

Frequently Asked Questions

Why doesn't Matterport show a square footage total?

Matterport's schematic floor plan is visual: it shows accurate room shapes and dimensions but does not aggregate them into a single GLA total. Calculating total square footage is left to the user with a measurement tool.

How accurate is Matterport's square footage measurement?

Matterport claims accuracy within 1% of actual dimensions for the Pro2 and Pro3 camera systems. Real-world accuracy varies based on scan overlap, complex geometry, and operator technique. Results are suitable for listing marketing and floor plan visualization; appraisers verify independently.

Does Matterport calculate GLA automatically?

Matterport generates a 'schematic floor plan' with room areas, but it does not automatically apply ANSI Z765 methodology. The platform measures interior dimensions and may include or exclude spaces differently than an ANSI exterior measurement. Manual review is required before using Matterport data for appraisal GLA.

What is the difference between Matterport square footage and appraisal GLA?

Matterport typically measures interior room areas, which exclude wall thickness. Appraisal GLA under ANSI Z765 uses exterior measurements, which include wall thickness. The Matterport figure will usually be smaller than the appraised GLA by a margin depending on the home's perimeter and wall thickness.

Can I use a Matterport floor plan export with MeasureFloorPlan?

Yes. Export your Matterport schematic floor plan as a PDF or image and upload it to MeasureFloorPlan. You can trace the perimeter and calculate total area. Keep in mind that Matterport floor plans use interior dimensions, so the result will differ from ANSI exterior-measured GLA. Use it for a quick estimate or cross-check, not as an official appraisal figure.

Do real estate agents rely on Matterport square footage?

Some agents use Matterport data for marketing descriptions, but the MLS square footage field should reflect the appraiser-verified or public record GLA. Matterport is best used for 3D tours and visual floor plan layouts rather than as the authoritative square footage source for a listing.

Can I measure each floor of a multi-story Matterport plan?

Yes. Matterport exports each floor as a separate page or section. Upload one floor at a time, set scale per floor, trace the perimeter of each, and add the floor totals together for total GLA.

Can you download a Matterport floor plan to verify square footage?

Yes. Matterport allows floor plan exports as PNG or PDF files depending on your subscription tier. Once downloaded, you can upload the floor plan to a tool like MeasureFloorPlan, trace the above-grade living areas, and cross-check the Matterport square footage against a manual GLA calculation. This is a fast way to catch any exclusion errors before the listing goes live.

Is Matterport square footage ANSI Z765 compliant?

Matterport Pro2 and Pro3 cameras can produce ANSI Z765-compliant GLA measurements through the Matterport Cortex AI system. However, ANSI compliance depends on proper setup and scan coverage. The camera must capture all exterior-accessible areas, and the resulting floor plan must be reviewed for accuracy. Many appraisers still independently verify Matterport measurements rather than relying on them exclusively.

How does Matterport calculate square footage from a 3D scan?

Matterport uses AI-based room segmentation to analyze point cloud data from the 3D scan. The system identifies floor planes, wall boundaries, and ceiling heights, then calculates floor area for each room and the overall structure. The resulting floor plan and square footage are derived from interior scan data. Exterior-measured GLA may differ slightly from Matterport results depending on wall thickness assumptions.
